1. Tighten the components below to the specified torque as follows :
Items Torque Nm (kgf·cm, lb·ft)
Driveshaft nut (2.0L)
Driveshaft nut (2.7L)
200~260
(2000~2600, 148~192)
200~280
(2000~2800, 148~207)
Lower arm ball joint to knuckle nut 60~72 (600~720, 44~53)
Knuckle to strut assembly nut 140~160
(1400~1600, 103~118)
2. Install the washer behind the driveshaft nut with the convex side outward as shown in the illustration.
DISASSEMBLY
1. After removing the screws(2) mounting the brake disc, remove the brake disc from the hub.
2. Remove the snap ring.
3. Install the special tools as illustrated.
4. Remove the hub from the knuckle by turning the special tool.
5. Remove the special tool and dust cover.
6. Remove the bearing inner race from the hub by using the special tool.
