TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Driveshaft and axle > General Information > Specifications,
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Driveshaft and axle > General Information > Specifications
SPECIFICATIONS
Driveshaft
Joint type 2.0L M/T 2.0L A/T 2.0L 6M/T 2.7L
Outer B.J. B.J. B.J. B.J.
Inner D.O.J. T.J. T.J. T.J.
Maximum permissible joint angle
B.J. 46° or more 45.8° or
more
46° or more 46.5° or
more
D.O.J. 22° or more
T.J. 23° or more 23° or more 23° or more
Hub end play mm(in.) 0.008 (0.0003) or less
Wheel bearing starting torque
Nm (kg·cm, lbf·ft)
1.8 (18, 1.33) or less
B. J. : Birfield joint
D.O.J. : Double offset joint
T. J. : Tripod joint
M/T : 5 Speed Manual transaxle
6M/T : 6 Speed Manual transaxle
A/T : Automatic transaxle
TIGHTENING TORQUE
Nm Kgf·cm lbf·ft
Driveshaft nut
2.0L
2.7L
200 ~ 260
200 ~ 280
2000 ~ 2600
2000 ~ 2800
148 ~ 192
148 ~ 207
Knuckle to strut assembly nut 140 ~ 160 1400 ~ 1600 104 ~ 118
Lower arm ball joint to knuckle nut 60 ~ 72 600 ~ 720 44 ~ 53
Tie rod end to knuckle 24 ~ 34 240 ~ 340 18 ~ 25
Front brake caliper to knuckle 69 ~ 85 690 ~ 850 51 ~ 63
Wheel nut 90 ~ 110 900 ~ 1100 66 ~ 81
Rear hub bearing flange nut 200 ~ 260 2000 ~ 2600 148 ~ 192
Rear brake to rear axle carrier mounting
bolt
65 ~ 75 650 ~ 750 48 ~ 56
Rear strut to carrier nut 110 ~ 130 1100 ~ 1300 81 ~ 96
Trailing arm to rear axle carrier mounting
nut
100 ~ 120 1000 ~ 1200 74 ~ 88
Rear suspension arm to rear axle carrier
mounting nut
160 ~ 180 1600 ~ 1800 118 ~ 133
Replace self-locking nuts with new ones after removal.
