TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > General Information > Troubleshooting,
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > General Information > Troubleshooting
TROUBLESHOOTING
Symptom Possible cause Remedy
Tachometer does not operate No.17 fuse (10A) blown
Tachometer faulty
Wiring faulty
Check for short and replace fuse
Check tachometer
Repair if necessary
Fuel gauge does not operate No.17 fuse (10A) blown
Fuel gauge faulty
Fuel sender faulty
Wiring faulty
Check for short and replace fuse
Check gauge
Check fuel sender
Repair if necessary
Low fuel warning lamp does not light No.17 fuse (10A) blown
Bulb burned out
Fuel level sensor faulty
Wiring or ground faulty
Check for short and replace fuse
Replace bulb
Check sensor
Repair if necessary
Water temperature gauge does not
operate
No.17 fuse (10A) blown
Water temperature gauge faulty
Water temperature sender faulty
Wiring or ground faulty
Check for short and replace fuse
Check gauge
Check sender
Repair if necessary
Oil pressure warning lamp does not
light
No.17 fuse (10A) blown
Bulb burned out
Oil pressure sender faulty
Wiring or ground faulty
Check for short and replace fuse
Replace bulb
Check sender
Repair if necessary
Low brake fluid warning lamp does not
light
No.17 fuse (10A) blown
Bulb burned out
Brake fluid level warning switch faulty
Parking brake switch faulty
Wiring or ground faulty
Check for short and replace fuse
Replace bulb
Check switch
Check switch
Repair if necessary
Open door warning lamp does not light No.18 fuse (10A) blown
Bulb burned out
Door switch faulty
Wiring or ground faulty
Check for short and replace fuse
Replace bulb
Check switch
Repair if necessary
Seat belt warning lamp does not light No.17 fuse (10A) blown
Bulb burned out
Buckle switch faulty
Wiring or ground faulty
Check for short and replace fuse
Replace bulb
Check switch
Repair if necessary
Symptom Possible cause Remedy
One lamp does not light
(all exterior)
Bulb burned out
Socket, wiring or ground faulty
Replace bulb
Repair if necessary
Head lamps do not light Bulb burned out
Head lamp fuse (15A) blown
No.21 fuse (10A) blown
Head lamp relay faulty
Lighting switch faulty
Wiring or ground faulty
Replace bulb
Replace fuse and check for short
Check for short and replace fuse
Check relay
Check switch
Repair if necessary
Tail lamps and license plate lamps do
not light
No.9, No.14 fuse (10A) blown
Battery fusible link (50A) blown
Tail lamp relay faulty
Lighting switch faulty
Wiring or ground faulty
Replace fuse and check for short
Replace the fusible link
Check relay
Check switch
Repair if necessary
Stop lamps do not light
No.13 fuse (15A) blown Replace fuse and check for short
