Wait at least 30 seconds after disconnecting the battery cable before doing any further work.
3. Remove the center crash pad side cover.
4. Remove Airbag SRSCM connector.
5. Connect deployment tool to the connector of each module.
6. At location as far away from the vehicle as possible, press the push button (removed from the vehicle) to
deploy the airbag.
1. Before deploying the airbag in this manner, first check to be sure that there is no one in or near the
vehicle. Wear safety glasses.
2.
The inflator will be quite hot immediately following the deployment, so wait at least 30 minutes to allow
it to cool before attempting to handle it. Although not poisonous, do not inhale gas from airbag
deployment. See Deployed Airbag Module Disposal Procedures for post-deployment handling
instructions.
3. If the airbag fails to deploy when the procedures above are followed, do not go near the module.
Contact your local distributor.
DEPLOYED AIRBAG MODULE DISPOSAL PROCEDURES
1. The inflator will be quite hot immediately following deployment, so wait at least 30 minutes to allow it to cool
before attempting to handle it.
2. Do not put water or oil on the airbag after deployment.
3. There may be adhered to the deployed airbag module, material that could irritate the eyes and/or skin, so
wear gloves and safety glasses when handling a deployed airbag module. If despite these precautions, the
material does get into your eyes or on your skin, immediately rinse the affected area with a large amount of
clean water. If any irritation develops, seek medical attention.
4. Tightly seal the airbag module in a strong vinyl bag for disposal.
