P4: PLC for SINUMERIK 828D
14.2 Programming Tool PLC828
Basic Functions
1092 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
14.2 Programming Tool PLC828
The "Programming Tool PLC 828" is the tool with which PLC programs can be generated in a user-friendly
fashion. This is a Windows program and must be installed on a Windows PC. This PC must be equipped with an
Ethernet port for online access to the control and must be connected to the control via the factory network or the
service interface.
References:
Commissioning Manual SINUMERIK828D
When calling the Programming Tool PLC828 – without specifying an existing project – then implicitly a new
project is created with the "Project1" default name. This project can be immediately used to generate the PLC
user program and then saved under any name and loaded into the control system.
Existing projects can be opened in the typical Windows fashion, also typical for Windows, a user-friendly online
help is available by pressing F1.
*60PRGHP
(WKHUQHW33IDFWRU\QHWZRUN
3&
3&3*
338KRUL]RQWDO
(WKHUQHW
6HUYLFH
LQWHUIDFH
+XE0RGXOH
'5,9(&/L4
56&
'0&
