R1: Reference point approach
15.11 Data lists
Basic Functions
1250 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
15.11 Data lists
15.11.1 Machine data
15.11.1.1 NC-specific machine data
15.11.1.2 Channelspecific machine data
15.11.1.3 Axis/spindlespecific machine data
Number Identifier: $MN_ Description
11300 JOG_INC_MODE_LEVELTRIGGRD INC/REF in jog/continuous mode
Number Identifier: $MC_ Description
20700 REFP_NC_START_LOCK NC start disable without reference point
Number Identifier: $MA_ Description
30200 NUM_ENCS Number of encoders
30240 ENC_TYP Actual value encoder type
30242 ENC_IS_INDEPENDENT Encoder is independent
30250 ACT_POS_ABS Absolute encoder position at time of deactivation.
30270 ENC_ABS_BUFFERING Absolute encoder: Traversing range extension
30300 IS_ROT_AX Rotary axis/spindle
30310 ROT_IS_MODULO Modulo conversion for rotary axis / spindle
30330 MODULO_RANGE Magnitude of the modulo range
30340 MODULO_RANGE_START Starting position of modulo range
30355 MISC_FUNCTION_MASK Axis functions
31122 BERO_DELAY_TIME_PLUS BERO delay time in plus direction
31123 BERO_DELAY_TIME_MINUS BERO delay time in minus direction
34000 REFP_CAM_IS_ACTIVE Axis with reference cam
34010 REFP_CAM_DIR_IS_MINUS Reference point approach in minus direction
34020 REFP_VELO_SEARCH_CAM Homing approach velocity
34030 REFP_MAX_CAM_DIST Maximum distance to reference cam
34040 REFP_VELO_SEARCH_MARKER Reference point creep velocity
34050 REFP_SEARCH_MARKER_REVERSE Direction reversal to reference cam
34060 REFP_MAX_MARKER_DIST Maximum distance to reference mark;
Max. distance to 2 reference mark for distance-coded
scales
34070 REFP_VELO_POS Reference point positioning velocity
34080 REFP_MOVE_DIST Reference point distance/destination point for
distancecoded system
