Siemens SINUMERIK 828D Function Manual

R1: Reference point approach
15.11 Data lists
Basic Functions
1252 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
15.11.2.3 Signals to channel
15.11.2.4 Signals from channel
15.11.2.5 Signals to axis/spindle
15.11.2.6 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Activate referencing DB21, ... .DBX1.0 DB3200.DBX1.0
OEM channel signal (HMI → PLC) REF DB21, ... .DBX28.7 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
Referencing active DB21, ... .DBX33.0 DB3300.DBX1.0
Reset DB21, ... .DBX35.7 DB3300.DBX3.7
All axes referenced DB21, ... .DBX36.2 DB3300.DBX4.2
Signal name SINUMERIK 840D sl SINUMERIK 828D
Followup mode (request) DB31, ... .DBX1.4 DB380x.DBX1.4
Position measuring system 1 / position measuring system
2
DB31, ... .DBX1.5/6 DB380x.DBX1.4
Reference point value 1 to 4 DB31, ... .DBX2.4-7 DB380x.DBX2.4-7
Traversing keys minus / plus DB31, ... .DBX4.6/7 DB380x.DBX4.6/7
Decelertion of reference point approach DB31, ... .DBX12.7 DB380x.DBX1000.7
Signal name SINUMERIK 840D sl SINUMERIK 828D
Referenced, synchronized 1 /
Referenced, synchronized 2
DB31, ... .DBX60.4/5 DB390x.DBX0.4/5
Followup mode active DB31, ... .DBX61.3 DB390x.DBX1.3
Traverse command minus / plus DB31, ... .DBX64.6/7 DB390x.DBX4.6/7
Restored 1 / Restored 2 DB31, ... .DBX71.4/5 DB390x.DBX11.4/5
