9.13 Program control
Basic Functions
614 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.13 Program control
Options
1. Function selection (via operator interface or PLC)
2. Activation of skip levels
3. Adapting the size of the interpolation buffer
4. Program display modes via an additional basic block display
5. Execution from external source (buffer size and number)
6. Execution from external subroutines
9.13.1 Function selection (via operator panel front or PLC)
Operator interface or PLC
The user can control part program execution via the operator panel front or PLC.
Selection, activation, feedback
Selection
Different functions are available under the Program control soft key. Selection affects an interface signal in the
PLC. These signals are to be understood as selection signals from the operator interface, and do not activate the
selected function.
Activation
These signal states must be transferred to another area of the data block to activate the selected function. With
program control by the PLC the signals are to be set directly.
Feedback
The activated functions are partly signaled back to the PLC from the NCK.
Table 9-9 Program control: Interface signals
Function Selection signal Activation signal Feedback signal
SKP skip block 0 to 7
SKP skip block 8 to 9
DB21, ... DBX26.0 - 26.7
DB21, ... DBX27.0 - 27.1
DB21, ... DBX2.0 - 2.7
DB21, ... DBX31.6 - 31.7
- - -
DRY dry run feedrate DB21, ... DBX24.6 DB21, ... DBX0.6 DB21, ... DBX318.6
ROV Rapid traverse override DB21, ... DBX25.3 DB21, ... DBX6.6 - - -
Single block: Preselection of SBL1, SBL2 or SBL3 via program control display of HMI
SBL1: Action single block HMI operator panel DB21, ... DBX0.4 - - -
SBL2: Decoding single block
SBL3: In cycle
M01 (Programmed stop) DB21, ... DBX24.5 DB21, ... DBX0.5 DB21, ... DBX32.5
Associated M01 DB21, ... DBX24.4 DB21, ... DBX30.5 DB21, ... DBX318.5
