A3: Axis Monitoring, Protection Zones
2.6 Data lists
Basic Functions
144 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
2.6.3 Signals
2.6.3.1 Signals to channel
Axis monitoring functions
None
Protection zones
2.6.3.2 Signals from channel
Axis monitoring functions
None
Protection zones
Signal name SINUMERIK 840D sl SINUMERIK 828D
Enable protection zones DB21, ... .DBX1.1 DB3200.DBX1.1
Feed disable DB21, ... .DBX6.0 DB3200.DBX6.0
Activate machinerelated protection zones 1-8 DB21, ... .DBX8.0-7 DB3200.DBX8.0-7
Activate machinerelated protection zone 9 DB21, ... .DBX9.0 DB3200.DBX9.0
Activate machinerelated protection zone 10 DB21, ... .DBX9.1 DB3200.DBX9.1
Activate channelspecific protection zone 1-8 DB21, ... .DBX10.0-7 DB3200.DBX10.0-7
Activate channelspecific protection zone 9 DB21, ... .DBX11.0 DB3200.DBX11.0
Activate channelspecific protection zone 10 DB21, ... .DBX11.1 DB3200.DBX11.1
Signal name SINUMERIK 840D sl SINUMERIK 828D
Machinerelated protection zones 1-8 preactivated DB21, ... .DBX272.0-7 DB3300.DBX8.0-7
Machinerelated protection zone 9 preactivated DB21, ... .DBX273.0 DB3300.DBX9.0
Machinerelated protection zone 10 preactivated DB21, ... .DBX273.1 DB3300.DBX9.1
Channelspecific protection zones 1-8 preactivated DB21, ... .DBX274.0-7 DB3300.DBX10.0-7
Channelspecific protection zone 9 preactivated DB21, ... .DBX275.0 DB3300.DBX11.0
Channelspecific protection zone 10 preactivated DB21, ... .DBX275.1 DB3300.DBX11.1
Machinerelated protection zones 1-8 violated DB21, ... .DBX276.0-7 DB3300.DBX12.0-7
Machinerelated protection zone 9 violated DB21, ... .DBX277.0 DB3300.DBX13.0
Machinerelated protection zone 10 violated DB21, ... .DBX277.1 DB3300.DBX13.1
Channelspecific protection zones 1-8 violated DB21, ... .DBX278.0-7 DB3300.DBX14.0-7
Channelspecific protection zone 9 violated DB21, ... .DBX279.0 DB3300.DBX15.0
Channelspecific protection zone 10 violated DB21, ... .DBX279.1 DB3300.DBX15.1
