S1: Spindles
16.11 Data lists
Basic Functions
1358 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
16.11 Data lists
16.11.1 Machine data
16.11.1.1 NC-specific machine data
16.11.1.2 Channelspecific machine data
16.11.1.3 Axis/spindlespecific machine data
Number Identifier: $MN_ Description
10192 GEAR_CHANGE_WAIT_TIME Wait time for acknowledgment of a gear stage change
during reorganization
10714 M_NO_FCT_EOP M function for spindle active after RESET
12060 OVR_SPIND_IS_GRAY_CODE Spindle override with Gray coding
12070 OVR_FACTOR_SPIND_SPEED Evaluation of spindle speed override switch
12080 OVR_REFERENCE_IS_PROG_FEED Override reference velocity
12082 OVR_REFERENCE_IS_MIN_FEED Defining the reference of the path override
12090 OVR_FUNCTION_MASK Selection of override specifications
Number Identifier: $MC_ Description
20090 SPIND_DEF_MASTER_SPIND Initial setting for master spindle on channel
20092 SPIND_ASSIGN_TAB_ENABLE Enabling/disabling of spindle converter
20850 SPOS_TO_VDI Output of M19 to the PLC with SPOS/SPOSA
22400 S_VALUES_ACTIVE_AFTER_RESET S function active after RESET
Number Identifier: $MA_ Description
30300 IS_ROT_AX Rotary axis
30310 ROT_IS_MODULO Modulo conversion
31044 ENC_IS_DIRECT2 Encoder on intermediate gear
31050 DRIVE_AX_RATIO_DENOM Denominator load gearbox
31060 DRIVE_AX_RATIO_NUMERA Numerator load gearbox
31064 DRIVE_AX_RATIO2_DENOM Intermediate gear denominator
31066 DRIVE_AX_RATIO2_NUMERA Intermediate gear numerator
31070 DRIVE_ENC_RATIO_DENOM Measuring gear denominator
31080 DRIVE_ENC_RATIO_NUMERA Measuring gear numerator
31122 BERO_DELAY_TIME_PLUS BERO delay time in plus direction
31123 BERO_DELAY_TIME_MINUS BERO delay time in minus direction
32200 POSCTRL_GAIN K
V
factor
32800 EQUIV_CURRCTRL_TIME Equivalent time constant current control circuit for
feedforward control
