K2: Axis Types, Coordinate Systems, Frames
10.5 Frames
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
799
10.5.12.4 Part program start
Frame conditions after part program start
10.5.12.5 Block search
Block search
Data management frames are also modified when carrying out a block search with calculation.
Cancellation of block search
If the block search is aborted with RESET, then the machine data:
MD28560 $MC_MM_SEARCH_RUN_RESTORE_MODE
can be used to configure that all data management frames are set to the value they had before the block search:
In case of cascaded block searches, the frames are set to the status of the previous block search.
SERUPRO
The "SERUPRO" function is not supported.
10.5.12.6 REPOS
There is no special treatment for frames. If a frame is modified in an ASUB, it is retained in the program. On
repositioning with REPOS, a modified frame is included, provided the modification was activated in the ASUB.
Frame Condition after parts program start
Programmable frame Deleted.
Settable frames Retained, depending on:
MD20112 $MC_START_MODE_MASK
Complete basic frame Retained
System frames Retained
External zero offset Retained
DRF offset Retained
Bit Significance
0 All frames in the data management are restored.
