K1: Mode group, channel, program operation, reset response
9.15 Replacing functions by subprograms
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
655
9.15.3.6 Example: Spindle positioning
In the subprogram, only the replacement of commands SPOS and SPOSA is explicitly executed. Additional
replacements should be supplemented in essentially the same fashion.
Parameterization
Main program
Replacement subprogram "LANG_SUB", version 1
Optimized for simplicity and velocity by directly addressing the spindles (S1: Leading spindle, S2: Following
spindle).
Machine data Meaning
MD30465 $MA_AXIS_LANG_SUB_MASK[AX5] =
'H0002'
Replace positioning commands
MD22080 $MC_AUXFU_PREDEF_SPEC[9] = 'H0021' Output of M19 to the PLC before
motion
Setting Data Meaning
SD43240 $SA_M19_SPOS[AX5] = 260 Spindle position for M19 = 260
SD43250 $SA_M19_SPOSMODE[AX5] = 4 Position approach mode for M19:
"Approach in the positive direction
(ACP)"
Programming Comment
PROC MAIN
...
N210 COUPON(S2,S1) ; Activate synchronous spindle coupling
N220 SPOS[1]=100 ; Position leading spindle with SPOS
...
N310 G01 F1000 X100 M19 ; Position leading spindle with M19
Programming Comment
N1000 PROC LANG_SUB DISPLOF SBLOF
N2100 IF($P_SUB_AXFCT==2)
N2110 ;Replacement of SPOS/SPOSA/M19 for active synchronous spindle coupling
N2185 DELAYFSTON ; Start stop delay area
N2190 COUPOF(S2,S1) ; Open synchronous spindle coupling
N2200 ; Position leading and following spindles
N2210 IF($P_SUB_SPOS==TRUE) OR ($P_SUB_SPOSA==TRUE)
N2220 ;SPOS and SPOSA are mapped to SPOS
