Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1679
19.6.4 Signals from channel (DB21, ...)
Signal state 0 or
edge change
1 → 0
No effect.
Corresponding to ... DB11, ... DBX0.7 (mode group reset)
DB21, ... DBX35.7 (channel status reset)
DB21, ...
DBX31.0 - DBX31.2 REPOS mode (REPOSPATHMODE)
Edge evaluation: no Signal(s) updated: Cyclic
REPOS mode specified by HMI:
Bit:2 1 0
0 0 0 = 0: no REPOS mode active
0 0 1 = 1: Re-approach to block start RMB
0 1 0 = 2: Re-approach to interruption point RMI
0 1 1 = 3: Re-approach to block end point RME
1 0 0 = 4: Re-approach to nearest path point RMN
Corresponding to ... DB21, ...DBX25.0 - DBX25.2 (REPOS mode (REPOSPATHMODE))
DB31, ... DBX10.0 (REPOSDELAY)
DB21, ...
DBX31.4 REPOS mode change (REPOSMODEEDGE)
Edge evaluation: yes Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
The REPOS mode has changed:
DB21, ... DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
Signal state 0 or
edge change
1 → 0
REPOS mode has not changed.
Corresponding to ... DB21, ... DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
DB21, ... DBX319.0 (REPOSMODEEDGEACKN)
DB21, ...DBX31.0 - DBX31.2 (REPOS mode (REPOSPATHMODE))
DB21, ...
DBX32.3 Action block active
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
The action block is being executed.
Signal state 0 or
edge change
1 → 0
No action block active.
Additional
references
/BA/ Operations Guide HMI (corresponding to the used software)
DB21, ...
DBX7.7 Reset
