K2: Axis Types, Coordinate Systems, Frames
10.5 Frames
Basic Functions
748 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
The fine component is transferred on saving the programmable frame in a local frame variable (LUD or GUD) and
on rewriting.
The table below shows the effect of various program commands on the absolute and additive translation.
10.5.5.7 Channelspecific system frames
Channelspecific system frames
System frames are only described by system functions, such as PRESET, scratching, zero offset external and
oblique processing. There are up to seven system frames per channel.
The valid system frames in the channel can be defined via machine data:
MD28082 $MC_MM_SYSTEM_FRAME_MASK (System frames SRAM)
Only system frames required for system functions should be configured, in the interests of memory space. Per
channel, each system frame occupies approx. 1 KB SRAM und approx. 6 KB DRAM. The system frame for
PRESET and scratching and the system frame for cycles are the default. Channel-specific system frames are
configured as bit codes, in accordance with the table below:
Coarse or absolute translation Fine or additive translation
TRANS X10
10 0
ATRANS X10
Unchanged alt_fine + 10
CTRANS(X,10)
10 0
CTRANS()
00
CFINE(X,10)
010
$P_PFRAME[X,TR] = 10
10 Unchanged
$P_PFRAME[X,FI] = 10
Unchanged 10
G58 X10
10 Unchanged
G59 X10
Unchanged 10
Bit Default System frame
0 1 PRESET and scratching
1 0 Zero offset external via system frames
20 TCARR and PAROT with an orientational toolholder
30 TOROT and TOFRAME
4 0 Frame for workpiece reference points
5RXJKRUDEVROXWH
7UDQVODWLRQ
)LQHRUDGGLWLYH
7UDQVODWLRQ
7UDQVODWLRQ
