Siemens SINUMERIK 828D Function Manual

K1: Mode group, channel, program operation, reset response
9.9 Program operation mode
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
567
9.9.7 Responses to operator or program actions
Status transitions
The following table shows the channel and program statuses that result after certain operator and program
actions.
The left-hand side of the table shows the channel and program statuses and the mode groups from which the
initial situation can be selected. Various operator/program actions are listed on the righthand side of the table,
the number of the situation after the action has been carried out is shown in brackets after each action.
M02/M30 in a block X
M00/M01 in a block X
IS "Single block" X
IS "Delete distancetogo" X
Auxiliary functions output to PLC but
not yet acknowledged
X
Wait instruction in program X
Table 9-7 Responses to operator or program actions
Situation
Channel
status
Program status Active mode
Operator or program action (Situation after the
action)
RVANVSWAAMJ
1 x x x RESET (4)
2 x x x RESET (5)
3 x x x RESET (6)
4 x x x NC Start (13); Mode change (5 or 6)
5 x x x NC Start (14); Mode change (4 or 6)
6 x x x Direction key (15); Mode change (4 or 5)
7 x x x NC Start (14)
8 x x x NC Start (15)
9 x x x NC Start (13); Mode change (10 or 11)
10 x x x NC Start (16); Mode change (9 or 11)
11 x x x Direction key (17); Mode change (9 or 10)
12 x x x NC Start (13); Mode change (10 or 11)
13 x x x NC Stop (12)
14 x x x NC Stop (7); at block end (5)
15 x x x NC Stop (8); at JOG end (6)
16 x x x NC Stop (10); at block end (10)
