K1: Mode group, channel, program operation, reset response
9.8 Block search Type 5 SERUPRO
Basic Functions
546 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.8.6 Special features in the part-program target block
9.8.6.1 STOPRE in the part-program target block
STOPRE block
The STOPRE block receives all modal settings from the preceding block and can, therefore, apply conditions in
advance in relation to the following actions:
• Synchronize program line currently processing with the main run.
• Derive modal settings for SERUPRO in order, for example, to influence this REPOS motion on approach of
SERUPRO.
Example 1:
Position a Z axis by specifying an X axis setpoint.
When block "G1 F100 Z=$AA_IM[X]" is interpreted, the preceding STOPRE block ensures synchronization with
the main run. The correct setpoint of the X axis is thus read via $AA_IM to move the Z axis to the same position.
Example 2:
Read and correctly calculate external zero offset.
Via an implicit STOPRE before N50, the NCK can read and correctly and correctly compute the current zero
offset.
For a SERUPRO operation on the search target N50 repositioning occurs in the SERUPRO approach to the
implicit STOPRE and the speed is determined from N40 with F5000.
N10 G1 X1000 F100 ;
N20 G1 X1000 F500 ;
N30 G1 X1000 F1000 ;
N40 G1 X1000 F5000 ;
N50 SUPA G1 F100 X200 ; move external zero offset after 200
N60 G0 X1000 ;
N70 ... ;
