H2: Auxiliary function outputs to PLC
8.3 Userdefined auxiliary functions
Basic Functions
422 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
8.3 Userdefined auxiliary functions
There are two uses for user-defined auxiliary functions:
• Extension of predefined auxiliary functions
• User-specific auxiliary functions
Extension of predefined auxiliary functions
Because there is only one set of machine data for the predefined auxiliary functions, they can only ever be used
to address one spindle of the channel. To address further spindles, user-defined auxiliary functions must be
parameterized to supplement the predefined auxiliary functions.
Extension of predefined auxiliary functions refers to the "address extensions" parameter. The number of the
spindle that the auxiliary function refers to is entered in the "address extension" parameter.
The relevant predefined auxiliary functions can be extended for the following system functions:
Example:
Extension of the predefined auxiliary function for the system function "spindle right" for the second and third
spindle of the channel.
System function Type
Address extension
1)
Value
Tool change M 1 6
Spindle right M 1 3
Spindle left M 1 4
Spindle stop M 1 5
Position spindle M 1 19
Axis mode M 1 70
Automatic gear stage M 1 40
Gear stage 1 M 1 41
Gear stage 2 M 1 42
Gear stage 3 M 1 43
Gear stage 4 M 1 44
Gear stage 5 M 1 45
Spindle speed S 1 -1
Tool selection T 1 -1
1)
Address extension = 1 is the default value used in the auxiliary functions predefined in the machine
data
Auxiliary function "spindle right" for the second spindle of the channel:
MD22010 $MC_AUXFU_ASSIGN_TYPE[ n ] = "M"
MD22020 $MC_AUXFU_ASSIGN_EXTENSION[ n ] = 2
MD22030 $MC_AUXFU_ ASSIGN_VALUE[ n ] = 3
