Z1: NC/PLC interface signals
19.11 Spindles (S1)
Basic Functions
1702 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
19.11 Spindles (S1)
19.11.1 Signals to axis/spindle (DB31, ...)
DB31, ...
DBX2.2 Spindle reset/delete distancetogo
Edge evaluation: yes Signal(s) updated: cyclic
Edge change
0 → 1
Independent of the machine data:
MD35040 $MA_SPIND_ACTIVE_AFTER_RESET
selects a spindle reset for the various spindle operating modes in the following fashion:
• Control mode:
– Spindle stops
– Program continues to run
– Spindle continues to run with subsequent M and S program commands
• Oscillating mode:
– Oscillation is interrupted
– Axes continue to run
– Program continues with the actual gearbox stage
– With the following M value and higher S value, it is possible that the IS:
DB31, ... DBX83.1 (programmed speed high)
is set.
• Positioning mode:
– Is stopped
• Axis operation:
– Is stopped
Signal state 0 or
edge change
1 → 0
No effect.
Corresponding to ... MD35040 $MA_SPIND_ACTIVE_AFTER_RESET (own spindle reset)
DB21, ... DBX7.7 (reset)
DB31, ... DBX2.2 (delete distance to go): is a different name for the same signal
