Siemens SINUMERIK 828D Function Manual

K1: Mode group, channel, program operation, reset response
9.9 Program operation mode
Basic Functions
568 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.9.8 Part-Program Start
Start handling
17 x x x NC Stop (11); at JOG end (11)
18 x x x Reset (4); wait for other channel (18)
Channel status Program status Operating modes
R --> aborted N --> aborted A --> aborted
U --> interrupted U --> interrupted M --> aborted
A --> running S --> stopped J --> aborted
W --> waiting
A --> running
Table 9-8 Typical program sequence
Sequence Command
Conditions
(must be satisfied before the
command)
Comments
1 Load program (via the operator
interface or part program)
2 Select AUTOMATIC mode
3 Program preselection Channel preselected
Preselected channel in
RESET state
User ID sufficient for
program preselection
4 NC start for preselected channel NC start disable not
available
Reference point approached in
all
axes
5 Program execution
6 M02/M30/RESET None End of program
Table 9-7 Responses to operator or program actions
Situation
Channel
status
Program status Active mode
Operator or program action (Situation after the
action)
RVANVSWAAMJ
