A2: Various NC/PLC interface signals and functions
1.4 Examples
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
67
1.4 Examples
Parameter set changeover
A parameter-set changeover is performed to change the position-control gain (servo gain factor) for machine axis
X1 from v = 4.0 to Kv = 0.5.
Preconditions
The parameter set changeover must be enabled by the machine data:
MD35590 $MA_PARAMSET_CHANGE_ENABLE [AX1] = 1 or 2 (parameter set change possible)
The 1st parameter set for machine axis X1 is set, in accordance with machine data with index "0" NC/PLC
interface:
DB31, … DBX9.0 - DBX9.2 = 0 (controller parameter set)
Parameter-set-dependent machine data
Parameter-set-dependent machine data are set as follows:
Machine data Comment
MD32200 $MA_POSCTRL_GAIN [0, AX1] = 4.0 Servo gain setting for parameter set 1
MD32200 $MA_POSCTRL_GAIN [1, AX1] = 2.0 Servo gain setting for parameter set 2
MD32200 $MA_POSCTRL_GAIN [2, AX1] = 1.0 Servo gain setting for parameter set 3
MD32200 $MA_POSCTRL_GAIN [3, AX1] = 0.5 Servo gain setting for parameter set 4
MD32200 $MA_POSCTRL_GAIN [4, AX1] = 0.25 Servo gain setting for parameter set 5
MD32200 $MA_POSCTRL_GAIN [5, AX1] = 0.125 Servo gain setting for parameter set 6
MD31050 $MA_DRIVE_AX_RATIO_DENOM [0, AX1] = 3 Denominator load gearbox for parameter set 1
MD31050 $MA_DRIVE_AX_RATIO_DENOM [1, AX1] = 3 Denominator load gearbox for parameter set 2
MD31050 $MA_DRIVE_AX_RATIO_DENOM [2, AX1] = 3 Denominator load gearbox for parameter set 3
MD31050 $MA_DRIVE_AX_RATIO_DENOM [3, AX1] = 3 Denominator load gearbox for parameter set 4
MD31050 $MA_DRIVE_AX_RATIO_DENOM [4, AX1] = 3 Denominator load gearbox for parameter set 5
MD31050 $MA_DRIVE_AX_RATIO_DENOM [5, AX1] = 3 Denominator load gearbox for parameter set 6
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [0, AX1] = 5 Counter load gearbox for parameter set 1
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [1, AX1] = 5 Counter load gearbox for parameter set 2
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [2, AX1] = 5 Counter load gearbox for parameter set 3
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [3, AX1] = 5 Counter load gearbox for parameter set 4
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [4, AX1] = 5 Counter load gearbox for parameter set 5
MD31060 $MA_DRIVE_AX_RATIO_NUMERA [5, AX1] = 5 Counter load gearbox for parameter set 6
MD35130 $MA_AX_VELO_LIMIT [0...5, AX1] Setting for each parameter set*)
MD32800 $MA_EQUIV_CURRCTRL_TIME [0..5, AX1] Setting for each parameter set*)
MD32810 $MA_EQUIV_SPEEDCTRL_TIME [0..5, AX1] Setting for each parameter set*)
MD32910 $MA_DYN_MATCH_TIME [0...5, AX1] Setting for each parameter set*)
*) The appropriate line must be specified separately for each parameter set according to the applicable syntax rules.
