B1: Continuouspath Mode, Exact Stop, LookAhead

3.10 Data lists

Basic Functions

212 Function Manual, 09/2011, 6FC5397-0BP40-2BA0

3.10 Data lists

3.10.1 Machine data

3.10.1.1 General machine data

3.10.1.2 Channelspecific machine data

Number Identifier: $MN_ Description

10110 PLC_CYCLE_TIME_AVERAGE Average PLC acknowledgment time

10680 MIN_CONTOUR_SAMPLING_TIME Minimum contour sampling time

10682 CONTOUR_SAMPLING_FACTOR Contour sampling factor

10712 NC_USER_CODE_CONF_NAME_TAB List of reconfigured NC commands

12030 OVR_FACTOR_FEEDRATE Evaluation of the path feed override switch

12100 OVR_FACTOR_LIMIT_BIN Limit for binarycoded override switch

18360 MM_EXT_PROG_BUFFER_SIZE FIFO buffer size for execution from external source

(DRAM)

Number Identifier: $MC_ Description

20150 GCODE_RESET_VALUES Initial setting of the groups

20170 COMPRESS_BLOCK_PATH_LIMIT Maximum traversing length of NC block for

compression

20172 COMPRESS_VELO_TOL Maximum permissible deviation from path feed for

compression

20400 LOOKAH_USE_VELO_NEXT_BLOCK LookAhead following block velocity

20430 LOOKAH_NUM_OVR_POINTS Number of override switch points for LookAhead

20440 LOOKAH_OVR_POINTS Override switch points for LookAhead

20443 LOOKAH_FFORM Activating the extended LookAhead

20450 LOOKAH_RELIEVE_BLOCK_CYCLE Relief factor for the block cycle time

20460 LOOKAH_SMOOTH_FACTOR Smoothing factor for LookAhead

20462 LOOKAH_SMOOTH_WITH_FEED Smoothing with programmed feed

20465 ADAPT_PATH_DYNAMIC Adaptation of path dynamic response

20480 SMOOTHING_MODE Rounding behavior with G64x

20482 COMPRESSOR_MODE Compressor mode

20488 SPLINE_MODE Setting for spline interpolation

20490 IGNORE_OVL_FACTOR_FOR_ADIS G641/G642 independent of the overload factor

20550 EXACT_POS_MODE Exact-stop conditions with G0/G1

20560 G0_TOLERANCE_FACTOR G0 tolerance factor

20600 MAX_PATH_JERK Pathrelated maximum jerk

20602 CURV_EFFECT_ON_PATH_ACCEL Influence of path curvature on path dynamic response

20603 CURV_EFFECT_ON_PATH_JERK Influence of path curvature on path jerk
