Siemens SINUMERIK 828D Function Manual

K2: Axis Types, Coordinate Systems, Frames
10.9 Data lists
Basic Functions
812 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
10.9.1.3 Channelspecific machine data
18600 MM_FRAME_FINE_TRANS Fine offset for FRAME (SRAM)
18601 MM_NUM_GLOBAL_USER_FRAMES Number of globally predefined user frames (SRAM)
18602 MM_NUM_GLOBAL_BASE_FRAMES Number of global basic frames (SRAM)
Number Identifier: $MC_ Description
20050 AXCONF_GEOAX_ASSIGN_TAB Assignment geometry axis to channel axis
20060 AXCONF_GEOAX_NAME_TAB Geometry axis name in channel
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
20080 AXCONF_CHANAX_NAME_TAB Channel axis name in the channel
20110 RESET_MODE_MASK Definition of basic control settings after RESET/TP-
End)
20118 GEOAX_CHANGE_RESET Allow automatic geometry axis change
20126 TOOL_CARRIER_RESET_VALUE Active toolholder on RESET
20140 TRAFO_RESET_VALUE Transformation record on power-up (RESET/TP-
End)
20150 GCODE_RESET_VALUES Initial setting of the G groups
20152 GCODE_RESET_MODE RESET response of the G Groups
20184 TOCARR_BASE_FRAME_NUMBER Number of the basic frame for pickup of the table
offset
21015 INVOLUTE_RADIUS_DELTA End point monitoring for evolvents (involutes)
22532 GEOAX_CHANGE_M_CODE M code for replacement of geometry axes
22534 TRAFO_CHANGE_M_CODE M code for transformation change
24000 FRAME_ADD_COMPONENTS Frame components for G58 and G59
24002 CHBFRAME_RESET_MASK RESET response of channelspecific basic frames
24004 CHBFRAME_POWERON_MASK Reset channel-specific basic frames after Power On
24006 CHSFRAME_RESET_MASK Active system frames after reset
24007 CHSFRAME_RESET_CLEAR_MASK Clear system frames on RESET
24008 CHSFRAME_POWERON_MASK Reset system frames after POWER ON
24010 PFRAME_RESET_MODE RESET mode for programmable frame
24020 FRAME_SUPPRESS_MODE Positions for frame suppression
24030 FRAME_ACT_SET SZS coordinate system setting
24040 FRAME_ADAPT_MODE Adapting active frames
24050 FRAME_SAA_MODE Saving and activating data management frames
24805 TRACYL_ROT_AX_FRAME_1 Rotary axis offset TRACYL 1
24855 TRACYL_ROT_AX_FRAME_2 Rotary axis offset TRACYL 2
24905 TRANSMIT_ROT_AX_FRAME_1 Rotary axis offset TRANSMIT1
24955 TRANSMIT_ROT_AX_FRAME_2 Rotary axis offset TRANSMIT2
28080 MM_NUM_USER_FRAMES Number of settable Frames (SRAM)
28081 MM_NUM_BASE_FRAMES Number of basic frames
Number Identifier: $MN_ Description
