Siemens SINUMERIK 828D Function Manual

W1: Tool offset
18.16 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1609
18.16.1.3 Axis/spindlespecific machine data
20184 TOCARR_BASE_FRAME_NUMBER Number of the basic frames to accept the table offset
20188 TOCARR_FINE_LIM_LIN Limit linear fine offset TCARR
20190 TOCARR_FINE_LIM_ROT Limit of the rotary fine offset TCARR
20202 WAB_MAXNUM_DUMMY_BLOCKS Maximum number of blocks with no traversing motions
with SAR
20204 WAB_CLEARANCE_TOLERANCE Direction reversal for WAB
20210 CUTCOM_CORNER_LIMIT Max. angle for intersection calculation with tool radius
compensation
20220 CUTCOM_MAX_DISC Maximum value for DISC
20230 CUTCOM_CURVE_INSERT_LIMIT Maximum value for intersection calculation with TRC
20240 CUTCOM_MAXNUM_CHECK_BLOCKS Blocks for predictive contour calculation with tool
radius compensation
20250 CUTCOM_MAXNUM_DUMMY_BLOCKS Maximum number of blocks without traversing motion
for TRC
20252 CUTCOM_MAXNUM_SUPPR_BLOCKS Maximum number of blocks with compensation
suppression
20256 CUTCOM_INTERS_POLY_ENABLE Intersection process possible for polynomials
20270 CUTTING_EDGE_DEFAULT Basic setting of tool cutting edge without programming
20272 SUMCORR_DEFAULT Initial setting of additive offset without program
20360 TOOL_PARAMETER_DEF_MASK Definition of tool parameters
20390 TOOL_TEMP_COMP_ON Activation of temperature compensation for tool length
20392 TOOL_TEMP_COMP_LIMIT Maximum temperature compensation for tool length
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
21080 CUTCOM_PARALLEL_ORI_LIMIT Minimum angle (path tangent and tool orientation) for
3D tool radius compensation
22530 TOCARR_CHANGE_M_CODE M code for change of toolholder
22550 TOOL_CHANGE_MODE New tool compensations with M function
22560 TOOL_CHANGE_M_CODE M function for tool change
22562 TOOL_CHANGE_ERROR_MODE Response when errors occur at tool change
24558 TRAFO5_JOINT_OFFSET_PART_1 Vector of kinematic offset in table, transformation 1
24658 TRAFO5_JOINT_OFFSET_PART_2 Vector of kinematic offset in table, transformation 2
28085 MM_LINK_TOA_UNIT Assigning ´the TO unit to a channel (SRAM)
Number Identifier: $MA_ Description
32750 TEMP_COMP_TYPE Temperature compensation type
