Page #1671 background imageLoading...
Page #1671 background image
Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1671
19.6.2 Signals from the mode group (DB11)
DB11
DBX1.7 Single block type A
Edge evaluation: No Signal(s) updated:
Signal state 1 or
edge change
0 1
DB11 DBX1.7 set and DB11 DBX1.6 not set: Response across modes
All channels are stopped.
All channels receive a start (start key).
Channel KS stops at the end of the block (due to single-block)
Channels KA receive a STOP command. (comparable to the STOP KEY).
All channels are stopped. (deceleration phase of all KAs)
(If DB11 DBX1.6 and DB11 DBX1.7 are set simultaneously, it is impossible to determine which
single block type is required. The control then assumes: No single block across mode groups).
Signal state 0 or
edge change
1 0
If DB11 DBX1.7 is not set and DB11 DBX1.6 is set, then it is single block type B.
(If DB11 DBX1.6 and DB11 DBX1.7 are not set, it is impossible to determine which single block type
is required. The control then assumes: No single block across mode groups).
Corresponding to ... Single block type B
DB11
DBX4.0 Selected mode AUTOMATIC
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 1
AUTOMATIC mode is selected by HMI.
Signal state 0 or
edge change
1 0
AUTOMATIC mode is not selected by HMI.
DB11
DBX4.1 Selected mode MDA
Edge evaluation: Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 1
MDA mode is selected by HMI.
Signal state 0 or
edge change
1 0
MDA mode is not selected by HMI.
