W1: Tool offset
18.11 Sum offsets and setup offsets
Basic Functions
1566 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
18.11.5 Upgrades for Tool Length Determination
18.11.5.1 Taking the compensation values into account location-specifically and
workpiecespecifically
Composition of the effective tool length
For a tool compensation without active kinematic transformation, the effective tool length consists of up to 8
vectors:
Type of action of the individual vectors
The type of action of the individual vectors or groups of vectors depends on the following further quantities:
• Tool length (geometry) ($TC_DP3 - $TC_DP5)
• Wear ($TC_DP12 - $TC_DP14)
• Tool base dimension (see note) ($TC_DP21 - $TC_DP23)
• Adapter dimension (see note) ($TC_ADPT1 - $TC_ADPT3)
• Total offsets fine ($TC_SCPx3 - $TC_SCPx5)
• Sum offsets coarse or setup offsets ($TC_ECPx3 - $TC_ECPx5)
• Offset vector l
1
of toolholder with orientation capability ($TC_CARR1 - $TC_CARR3)
• Offset vector l
2
of toolholder with orientation capability ($TC_CARR4 - $TC_CARR6)
• Offset vector l
3
of toolholder with orientation capability ($TC_CARR15 - $TC_CARR17)
Note
The tool base dimension and adapter dimension can only be applied as alternatives.
Influencing quantity Operating principle
G codes Active processing level
Tool type Milling tool or turning/grinding tools
Machine data Tool management active/not active, toolholder with
orientation capability available/not available
Setting data Behavior of tool length components when mirroring or
when changing the plane
Toolholder with orientation capability Set values of toolholder with orientation capability
Adapter transformations Transformed tool compensation values
