Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.1 Various interface signals and functions (A2)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1623
19.1.6 Signals to channel (DB21, ...)
DB19
DBX26.5 Unload (job list selection from PLC, status)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Unload active
Signal state 0 or
edge change 1 → 0
Unload inactive
Corresponding to ... Valid for HMI Advanced
DB19
DBX26.6 Load (job list selection from PLC, status)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Loading active
Signal state 0 or
edge change 1 → 0
Loading inactive
Corresponding to ... Valid for HMI Advanced
DB19
DBX26.7 Selection (job list selection from PLC, status)
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Selection active
Signal state 0 or
edge change 1 → 0
Selection inactive
Corresponding to ... Valid for HMI Advanced
DB19
DBB27. Error program handling
Edge evaluation: no Signal(s) updated: Cyclic
DB21, ...
DBX6.2 Delete distancetogo (channelspecific)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change 0 → 1
Delete distancetogo (channelspecific):
IS "Delete distancetogo (channelspecific)" for path axes is only active in AUTOMATIC mode.
The rising edge of the interface signal is only effective for the axes involved in the geometry
grouping. These are also stopped with a ramp stop and their distancetogo deleted (setpoint -
actual value difference). Any remaining following error is not removed. The next program block is
then started.
IS "Delete distancetogo (channelspecific)" is therefore ignored by positioning axes.
Note:
IS "Delete distancetogo" does not influence the running dwell time in a program block with dwell
time.
