P3: Basic PLC Program for SINUMERIK 840D sl
13.2 Key data of the PLC-CPUs for 840D sl and 840Di sl
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
839
13.2 Key data of the PLC-CPUs for 840D sl and 840Di sl
Scope of performance
The table given below shows the performance range of the PLC CPUs and the scope of the basic PLC program
with reference to various types of control.
Type of control
840Di sl 840D sl (NCU 710.2)
PLC CPU: Integrated PLC 317-2DP Integrated PLC 317-2DP
1)
Firmware release:
FW 2.1 FW 2.1
Key CPU data
Memory for user and basic program 128 to 768 KB 128 to 768 KB
Data block memory Max. 256 KB Max. 256 KB
Memory submodule No No
Bit memories 32768 32768
Timers 512 512
Counter 512 512
Clock memory 8 8
System functions
SFB 0-5, 32, 52-54, 75 0-5, 32, 52-54, 75
SFC 0-7, 11-15, 17-24, 28-34, 36-
44, 46, 47, 49-52, 54-59, 64-
69, 72-74, 81, 101
0-7, 11-15, 17-24, 28-34, 36-
44, 46, 47, 49-52, 54-59, 64-
69, 72-74, 81, 101
Program/data blocks
OB 1, 10, 20-21, 32-35, 40,
55-57, 80-82, 85-87, 100,
121-122
1, 10, 20-21, 32-35, 40,
55-57, 80-82, 85-87, 100,
121-122
FB 0-2048 0-2048
FC 0-2048 0-2048
DB 1-2048 1-2048
Max. block length DB 64 KB 64 KB
Max. block length FC, FB 64 KB 64 KB
Inputs/outputs
Logical I/O addressing range 0-8191 0-8191
Reserv. log. addressing range for drives 4096-8191 4096-8191
Process image (fixed) 0-255 0-255
Notice: The inputs/outputs above 4096 are reserved for integrated drives.
1)
Firmware release: Release of the SIMATIC CPU, from which the SINUMERIK PLC CPU is derived.
