S1: Spindles
16.11 Data lists
Basic Functions
1360 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
16.11.2 Setting data
16.11.2.1 Channelspecific setting data
16.11.2.2 Axis/spindle-specific setting data
35410 SPIND_OSCILL_ACCEL Oscillation acceleration
35430 SPIND_OSCILL_START_DIR Oscillation start direction
35440 SPIND_OSCILL_TIME_CW Oscillation time for M3 direction
35450 SPIND_OSCILL_TIME_CCW Oscillation time for M4 direction
35500 SPIND_ON_SPEED_AT_IPO_START Feed enable with spindle in setpoint range
35510 SPIND_STOPPED_AT_IPO_START Feed enable with stationary spindle
35550 DRILL_VELO_LIMIT[n] Maximum speeds for tapping
35590 PARAMSET_CHANGE_ENABLE Parameter set definition possible from PLC
36060 STANDSTILL_VELO_TOL Threshold velocity "Axis/spindle stationary"
36200 AX_VELO_LIMIT Threshold value for velocity monitoring.
Number Identifier: $SC_ Description
42600 JOG_FEED_PER_REF_SOURCE Revolutional feedrate control in JOG mode
42800 SPIND_ASSIGN_TAB Spindle number converter
42900 MIRROR_TOOL_LENGTH Mirror tool length offset
42910 MIRROR_TOOL_WEAR Mirror wear values of tool length compensation
42920 WEAR_SIGN_CUTPOS Mirror wear values of machining plane
42930 WEAR_SIGN Invert sign of all wear values
42940 TOOL_LENGTH_CONST Retain the assignment of tool length components
when changing the machining plane (G17 to G19)
Number Identifier: $SA_ Description
43200 SPIND_S Speed for spindle start via PLC interface
43202 SPIND_CONSTCUT_S Cutting rate for spindle start via PLC interface
43206 SPIND_SPEED_TYPE For spindle start via PLC interface
43210 SPIND_MIN_VELO_G25 Progr. Spindle speed limiting G25
43220 SPIND_MAX_VELO_G26 Progr. Spindle speed limiting G26
43230 SPIND_MAX_VELO_LIMS Progr. spindle speed limiting G96/G961
43235 SPIND_USER_VELO_LIMIT Maximum spindle speed
43240 M19_SPOS Spindle position for spindle positioning with M19
43250 M19_SPOSMODE Spindle positioning approach mode for spindle
positioning with M19
43300 ASSIGN_FEED_PER_REF_SOURCE Rotational feedrate for positioning axes/spindles
Number Identifier: $MA_ Description
