Siemens SINUMERIK 828D Function Manual

K2: Axis Types, Coordinate Systems, Frames
10.9 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
811
10.9 Data lists
10.9.1 Machine data
10.9.1.1 Displaying machine data
10.9.1.2 NC-specific machine data
Number Identifier: $MM_ Description
SINUMERIK Operate
9242 MA_STAT_DISPLAY_BASE Numerical basis for display of moving
joint STAT
9243 MA_TU_DISPLAY_BASE Numerical basis for display of rotary
axis position TU
9244 MA_ORIAXES_EULER_ANGLE_NAME Display of orientation axes as Euler
angle
9245 MA_PRESET_FRAMEIDX Value storage scratching and
PRESET
9247 USER_CLASS_BASE_ZERO_OFF_PA Availability of basic offset in
"Parameters" operating area
9248 USER_CLASS_BASE_ZERO_OFF_MA Availability of basic offset in Machine
operating area
9424 MA_COORDINATE_SYSTEM Coordinate system for actualvalue
display
9440 ACTIVE_SEL_USER_DATA Active data (frames) are immediately
operative after editing
9449 WRITE_TOA_LIMIT_MASK Applicability of MD9203 to edge data
and locationdependent offsets
9450 MM_WRITE_TOA_FINE_LIMIT Limit value for wear fine
9451 MM_WRITE_ZOA_FINE_LIMIT Limit value for offset fine
Number Identifier: $MN_ Description
10000 AXCONF_MACHAX_NAME_TAB Machine axis name
10600 FRAME_ANGLE_INPUT_MODE Sequence of rotation in the frame
10602 FRAME_GEOAX_CHANGE_MODE Frames and switchover of geometry axes
10610 MIRROR_REF_AX Reference axis for mirroring
10612 MIRROR_TOGGLE Change over mirror
10613 NCBFRAME_RESET_MASK ActiveNCU-global basic frame after reset
10615 NCBFRAME_POWERON_MASK Reset global basic frames after Power On
10617 FRAME_SAVE_MASK Behavior of frames for SAVE subprograms
10650 IPO_PARAM_NAME_TAB Name of interpolation parameters
10660 INTERMEDIATE_POINT_NAME_TAB Name of intermediate point coordinates for G2/G3
11640 ENABLE_CHAN_AX_GAP Channel axis gaps are allowed
