B2: Acceleration

4.4 Data lists

Basic Functions

Function Manual, 09/2011, 6FC5397-0BP40-2BA0

263

4.4 Data lists

4.4.1 Machine data

4.4.1.1 Channelspecific machine data

4.4.1.2 Axis/spindlespecific machine data

Number Identifier: $MC_ Description

20150 GCODE_RESET_VALUES Initial setting of the G groups

20500 CONST_VELO_MIN_TIME Minimum time with constant velocity

20600 MAX_PATH_JERK Path-related maximum jerk

20602 CURV_EFFECT_ON_PATH_ACCEL Influence of path curvature on path dynamic response

20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements

Number Identifier: $MA_ Description

32000 MAX_AX_VELO Maximum axis velocity

32300 MAX_AX_ACCEL Maximum axis acceleration

32310 MAX_ACCEL_OVL_FACTOR Overload factor for velocity jump

32320 DYN_LIMIT_RESET_MASK Reset behavior of dynamic limits

32400 AX_JERK_ENABLE Axial jerk limitation

32402 AX_JERK_MODE Filter type for axial jerk limitation

32410 AX_JERK_TIME Time constant for axial jerk filter

32420 JOG_AND_POS_JERK_ENABLE Initial setting for axial jerk limitation

32430 JOG_AND_POS_MAX_JERK Axial jerk

32431 MAX_AX_JERK Maximum axial jerk at the block transition in

continuous-path mode

32432 PATH_TRANS_JERK_LIM Max. axial jerk of a geometry axis at block boundary

32433 SOFT_ACCEL_FACTOR Scaling of acceleration limitation for SOFT

32434 G00_ACCEL_FACTOR Scaling of acceleration limitation for G00

32435 G00_JERK_FACTOR Scaling of axial jerk limitation for G00

32436 JOG_MAX_JERK Maximum axial jerk for JOG motion

32437 AX_JERK_VEL0 First velocity threshold for velocity-dependent jerk

adaptation

32438 AX_JERK_VEL1 Second velocity threshold for the velocity-dependent

jerk adaptation

32439 MAX_AX_JERK_FACTOR Factor to set the maximum jerk for higher velocities

(velocity-dependent jerk adaptation)

35220 ACCEL_REDUCTION_SPEED_POINT Speed for reduced acceleration
