Siemens SINUMERIK 828D Function Manual

K1: Mode group, channel, program operation, reset response
9.9 Program operation mode
Basic Functions
588 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.9.13 Influencing the Stop events through Stop delay area
Stop Delay Area
The reaction to a stop event can be influenced by conditioned interruptible area in the current part program. Such
a program area is called stop delay area.
Within the stop delay areas there should be no stop and the feed should not be changed. Stops do not take effect
until the program section has been completed (Example: making of a thread).
A stop delay area is defined with the part program commands:
References:
Programming Manual, Job Planning;
Stop events
Overview of the NCK events that cause a stop:
DELAYFSTON
Start a Stop Delay Area
DELAYFSTOF
End a Stop Delay Area
NCK events Response Stop criteria
Reset and mode group RESET immediate IS: DB21, ... DBX7.7 and DB11 DBX20.7
PROG_END Alarm 16954 NC prog.: M30
Interrupt delayed IS: "FC-9" and ASUP DB10 DBB1
DELDISTOGO_SYNC immediate IS: "Delete distance-to-go" DB21, ... DBX6.2 and axial
PROGRESETREPEAT delayed IS: "Clear number of subprogram passes" DB21, ...
DBX6.3
PROGCANCELSUB delayed IS: "Program level abort" DB21, ... DBX6.4
SINGLEBLOCKSTOP delayed In the stop delay area: NC stops at the end of the 1st
block outside the stop delay area.
Sinlge block is active before the stop delay area:
IS: "NC Stop at block limit" DB21, ... DBX7.2
SINGLEBLOCK_IPO delayed IS: "Activate single-block type 1" DB11 DBX21.7
SINGLEBLOCK_DECODIER delayed IS: "Activate single-block type 2" DB11 DBX21.6
STOPALL immediate IS: DB21, ... DBX7.4 and DB11 DBX20.6
STOPPROG delayed IS: DB21, ... DBX7.3 and DB11 DBX20.5
OVERSTORE_BUFFER_END_REACHED Alarm 16954 NC prog.: Stop because of empty overstore buffer
PREP_STOP Alarm 16954 NC prog.: STOPRE and all implicit Stopres
PROG_STOP Alarm 16954 NC prog.: M0 and M1
STOPPROGATBLOCKEND delayed IS: "NC Stop at block limit" DB21, ... DBX7.2
STOPPROGATSUPEND System fault SR end should always deselect the stop delay section.
WAITM Alarm 16954 NC prog.: WAITM
WAITE Alarm 16954 NC prog.: WAITE
INIT_SYNC Alarm 16954 NC prog.: INIT with parameter "S"
MMCCMD Alarm 16954 NC prog.: MMC( STRING, CHAR )
