Siemens SINUMERIK 828D Function Manual

S1: Spindles
16.11 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1361
16.11.3 signals
16.11.3.1 Signals to axis/spindle
16.11.3.2 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Feedrate override A to H DB31, ... .DBX0.0-7 DB380x.DBX0.0-7
Axis/spindle disable DB31, ... .DBX1.3 DB380x.DBX1.3
Followup mode DB31, ... .DBX1.4 DB380x.DBX1.4
Position measuring system 1 DB31, ... .DBX1.5 DB380x.DBX1.5
Position measuring system 2 DB31, ... .DBX1.6 DB380x.DBX1.6
Override active DB31, ... .DBX1.7 DB380x.DBX1.7
Controller enable DB31, ... .DBX2.1 DB380x.DBX2.1
Spindle reset/delete distancetogo DB31, ... .DBX2.2 DB380x.DBX2.2
Velocity/spindle speed limitation DB31, ... .DBX3.6 DB380x.DBX3.6
Program test Axis/Spindle Enable DB31, ... .DBX3.7 DB380x.DBX3.7
Actual gear step A to C DB31, ... .DBX16.0-2 DB380x.DBX2000.0-2
Gear changed DB31, ... .DBX16.3 DB380x.DBX2000.3
Resynchronize spindle 1 DB31, ... .DBX16.4 DB380x.DBX2000.4
Resynchronize spindle 2 DB31, ... .DBX16.5 DB380x.DBX2000.5
no n-monitoring with gear change DB31, ... .DBX16.6 DB380x.DBX2000.6
Delete S value DB31, ... .DBX16.7 DB380x.DBX2000.7
Feedrate override for spindle valid DB31, ... .DBX17.0 DB380x.DBX2001.0
Resynchronize spindle during positioning 1 DB31, ... .DBX17.4 DB380x.DBX2001.4
Resynchronize spindle during positioning 2 DB31, ... .DBX17.5 -
Invert M3/M4 DB31, ... .DBX17.6 DB380x.DBX2001.6
Oscillation via PLC DB31, ... .DBX18.4 DB380x.DBX2002.4
Oscillation enable (oscillation speed) DB31, ... .DBX18.5 DB380x.DBX2002.5
Oscillation rotation direction clockwise (Set rotation
direction clockwise)
DB31, ... .DBX18.6 DB380x.DBX2002.6
Oscillation rotation direction counterclockwise (Set rotation
direction counterclockwise)
DB31, ... .DBX18.7 DB380x.DBX2002.7
Spindle override A to H DB31, ... .DBX19.0-7 DB380x.DBX2003.0-7
Signal name SINUMERIK 840D sl SINUMERIK 828D
Spindle/No Axis DB31, ... .DBX60.0 DB390x.DBX0.0
Encoder limit frequency exceeded 1 DB31, ... .DBX60.2 DB390x.DBX0.2
Encoder limit frequency exceeded 2 DB31, ... .DBX60.3 -
Homed/synchronized 1 DB31, ... .DBX60.4 DB390x.DBX0.4
Homed/synchronized 2 DB31, ... .DBX60.5 DB390x.DBX0.5
Position reached with exact stop coarse DB31, ... .DBX60.6 DB390x.DBX0.6
Position reached with exact stop fine DB31, ... .DBX60.7 DB390x.DBX0.7
