W1: Tool offset
18.10 Special handling of tool compensations
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1545
18.10 Special handling of tool compensations
18.10.1 Relevant setting data
SD42900- 42960
Setting data SD42900 - SD42940 can be used to make the following settings with reference to tool
compensation:
• Sign of the tool length
• Sign of the wear
• Behavior of the wear components when mirroring geometry axes
• Behavior of the wear components when changing the machining plane via setting data
• Allocation of the tool length components independent of actual tool type
• Transformation of wear components into a suitable coordinate system for controlling the effective tool length
You will find detailed information about sum and tool offsets in:
References:
/FBW/ Function Manual Tool Management
/PG/ Programming Manual Fundamentals; Tool Compensations
Required setting data
• SD42900 $SC_MIRROR_TOOL_LENGTH (mirroring of tool length components and components of the tool
base dimension)
• SD42910 $SC_MIRROR_TOOL_WEAR (mirroring of wear values of tool length components)
• SD42920 $SC_WEAR_SIGN_CUTPOS (sign evaluation of the wear components)
• SD42930 $SC_WEAR_SIGN (inverts the sign of the wear dimensions)
• SD42940 $SC_TOOL_LENGTH_CONST (allocation of the tool length components to the geometry axes)
• SD42950 $SC_TOOL_LENGTH_TYPE (allocation of the tool length components independent of tool type)
• SD42935 $SC_WEAR_TRANSFORM (transformation of wear values)
• SD42960 $SC_TOOL_TEMP_COMP (tool length offsets)
Note
In the following description, the wear includes the total values of the following
components:
• Wear values: $TC_DP12 to $TC_DP20
• Sum offset, consisting of:
– Wear values: $SCPX3 to $SCPX11
– Setup values: $ECPX3 to $ECPX11
