W1: Tool offset
18.16 Data lists
Basic Functions
1610 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
18.16.2 Setting data
18.16.2.1 Channelspecific setting data
18.16.3 Signals
18.16.3.1 Signals from channel
Number Identifier: $SC_ Description
42442 TOOL_OFFSET_INCR_PROG Tool length compensation
42470 CRIT_SPLINE_ANGLE Core limit angle, for compressor
42480 STOP_CUTCOM_STOPRE Alarm response for tool radius compensation and
preprocessing stop
42494 CUTCOM_ACT_DEACT_CTRL Approach and retraction behavior for tool radius
compensation
42496 CUTCOM_CLSDT_CONT Behavior of the tool radius compensation for closed
contour
42900 MIRROR_TOOL_LENGTH Sign change, tool lengths when mirroring
42910 MIRROR_TOOL_WEAR Sign change, tool wear when mirroring
42920 WEAR_SIGN_CUTPOS Sign of wear for tools with cutting edge position
42930 WEAR_SIGN Sign of the wear
42935 WEAR_TRANSFORM Transformations for tool components
42940 TOOL_LENGTH_CONST Change of tool length components for change of plane
42950 TOOL_LENGTH_TYPE Assignment of the tool length offset independent of
tool type
42960 TOOL_TEMP_COMP Temperature compensation value in relation to tool
42974 TCARR_FINE_CORRECTION Fine offset TCARR on/off
42984 CUTDIRMOD Modification of $P_AD[2] or $P_AD[11]
Signal name SINUMERIK 840D sl SINUMERIK 828D
T function 1 change DB21, ... .DBX61.0 -
D function 1 change DB21, ... .DBX62.0 -
T function 1 DB21, ... .DBB116-119 DB2500.DBD2000
D function 1 DB21, ... .DBB128-129 DB2500.DBD5000
Active G function of group 7 DB21, ... .DBB214 DB3500.DBB6
Active G function of group 16 DB21, ... .DBB223 DB3500.DBB15
Active G function of group 17 DB21, ... .DBB224 DB3500.DBB16
Active G function of group 18 DB21, ... .DBB225 DB3500.DBB17
Active G function of group 23 DB21, ... .DBB230 DB3500.DBB22
