Siemens SINUMERIK 828D Function Manual

K2: Axis Types, Coordinate Systems, Frames
10.9 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
815
10.9.4 Signals
10.9.4.1 Signals from channel
10.9.4.2 Signals to axis/spindle
10.9.4.3 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
T function modification DB21, ... .DBX61.0-.2 -
D function modification DB21, ... .DBX62.0-.2 -
T function 1 DB21, ... .DBB118-119 DB2500.DBD2000
D function 2 DB21, ... .DBB129 DB2500.DBD5000
Number of active function G group 1 8 (bit int) DB21, ... .DBB208 DB3500.DBB0
Number of active function G group 2 8 (bit int) DB21, ... .DBB209 DB3500.DBB1
... ... …
Number of active function G group 29 8 (bit int) DB21, ... .DBB236 DB3500.DBB28
Signal name SINUMERIK 840D sl SINUMERIK 828D
Accept zero offset external DB31, ... .DBX3.0 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
Spindle/no axis DB31, ... .DBX60.0 DB390x.DBX0.0
