Siemens SINUMERIK 828D Function Manual

P4: PLC for SINUMERIK 828D
14.3 Programming
Basic Functions
1100 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
14.3.2.2 Addressing range of the target system
Address range of a memory type is the addressing range for this type of memory that spans the lowest and
highest possible address numbers. The lowest and highest possible address number depends on the particular
memory type.
If you execute operations, which communicate with the target system, then the Programming Tool PLC828
recognizes your CPU version. When generating your program, you must ensure that you only use the address
range valid for this CPU. If you attempt to load a program that accesses addresses ranges, which are not valid for
this CPU, then an error message is output.
Address ranges
Access method Type of memory Min. and max. address numbers
Bit (byte.bit) I
0.0 - 255.7
1)
256.0 - 256.3
2)
Q
0.0 - 255.7
1)
256.0 - 256.3
2)
M 0.0 - 999.7
SM 0.0 - 0.6
T 0 - 15 (100 ms)
16 – 127 (10 ms)
C0 – 63
L 0.0 - 59.7
Byte IB
0 - 255
1)
QB
0 - 255
1)
MB 0 – 999
SMB 0
LB 0 - 59
AC 0 - 3
Word IW
0 - 254
1)
QW
0 - 254
1)
MW 0 – 998
T 0 - 15 (100 ms)
16 - 127 (10 ms)
C0 – 63
LW 0 – 58
AC 0 – 3
Double word ID
0 - 252
1)
QD
0 - 252
1)
MD 0 996
LD 0 - 56
AC 0 - 3
