W1: Tool offset
18.10 Special handling of tool compensations
Basic Functions
1550 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Toolholder with orientation capability
Setting data SD42900 - SD42950
Setting data SD42900 - SD42950 have no effect on the components of an active toolholder with orientation
capability. The calculation with a toolholder with orientation capability always allows for a tool with its total
resulting length (tool length + wear + tool base dimension). The calculation of the resulting total length allows for
all modifications caused by the setting data.
18.10.6 Temperature offsets in tool direction (SD42960 $SC_TOOL_TEMP_COMP)
18.10.7 Tool lengths in the WCS, allowing for the orientation
Change tool or working plane
The values displayed for the tool correspond to the expansion in the WCS. If a toolholder with an inclined
clamping position is to be used, you should make sure that the transformation used supports the toolholder. If
this is not the case, incorrect tool dimensions will be displayed. When changing the working plane from G17 to
G18 or G19, you should ensure that the transformation can also be used for these working planes. If the
transformation is only available for G17 machining, the dimensions continue to be displayed for a tool in the Z
direction after the plane change.
When transformation is deactivated, the basic tool is displayed in the x, y or z direction, according to the working
plane. Allowance is made for a programmed toolholder. These tool dimensions are not altered when traversing
without a transformation.
Note
When toolholders with orientation capability are used, it is common to define all tools for a
non-mirrored basic system, even those, which are only used for mirrored machining. When
machining with mirrored axes, the toolholder is then rotated such that the actual position of
the tool is described correctly. All tool-length components then automatically act in the
correct direction, dispensing with the need for control of individual component evaluation via
setting data, depending on the mirroring status of individual axes.
The use of toolholders with orientation capability is also practical if the physical
characteristics of the machine type prevents tools, which are permanently installed with
different orientations, from being rotated. Tool dimensioning can then be performed uniformly
in a basic orientation, where the dimensions relevant for machining are calculated according
to the rotations of a virtual toolholder.
Note
Temperature offset in the tool direction is operative only as an option with generic 5axis
transformation, types 24 and 56.
