H2: Auxiliary function outputs to PLC
8.18 Data lists
Basic Functions
476 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
8.18.2.3 Signals to axis/spindle
8.18.2.4 Signals from axis/spindle
F function 5 (real) DB21, ... .DBB184-187 -
Extended address F function 6 (16 bit int) DB21, ... .DBB188-189 -
F function 6 (real) DB21, ... .DBB190-193 -
Dynamic M function: M00 - M07 DB21, ... .DBB194 DB2500.DBB1000
Dynamic M function: M08 - M15 DB21, ... .DBB195 DB2500.DBB1001
Dynamic M function: M16 - M23 DB21, ... .DBB196 DB2500.DBB1002
Dynamic M function: M24 - M31 DB21, ... .DBB197 DB2500.DBB1003
Dynamic M function: M32 - M39 DB21, ... .DBB198 DB2500.DBB1004
Dynamic M function: M40 - M47 DB21, ... .DBB199 DB2500.DBB1005
Dynamic M function: M48 - M55 DB21, ... .DBB200 DB2500.DBB1006
Dynamic M function: M56 - M63 DB21, ... .DBB201 DB2500.DBB1007
Dynamic M function: M64 - M71 DB21, ... .DBB202 DB2500.DBB1008
Dynamic M function: M72 - M79 DB21, ... .DBB203 DB2500.DBB1009
Dynamic M function: M80 - M87 DB21, ... .DBB204 DB2500.DBB1010
Dynamic M function: M88 - M95 DB21, ... .DBB205 DB2500.DBB1011
Dynamic M function: M96 - M99 DB21, ... .DBX206.0-3 DB2500.DBB1012.0-3
Associated M00/M01 active DB21, ... .DBX318.5 DB3300.DBX4002.5
Signal name SINUMERIK 840D sl SINUMERIK 828D
F function for positioning axis (real) DB31, ... .DBB78-81 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
M function for spindle (Int) DB21, ... .DBB86-87 DB370x.DBD0000
S function for spindle (real) DB21, ... .DBB88-91 DB370x.DBD0004
Signal name SINUMERIK 840D sl SINUMERIK 828D
