W1: Tool offset
18.2 Tool
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1437
18.2.7 Definition of the effect of the tool parameters
MD20360
The effect of the tool parameters on the transverse axis in connection with diameter programming can be
controlled selectively with the machine data:
MD20360 $MC_TOOL_PARAMETER_DEF_MASK (definition of tool parameters).
Details are described with the mentioned MD
DRF handwheel traversal with half distance
During DRF handwheel traversal, it is possible to move a transverse axis through only half the distance of the
specified increment as follows:
Specify the distance with handwheel via the machine data:
MD11346 $MN_HANDWHEEL_TRUE_DISTANCE = 1 (handwheel path or speed specification).
Define the DRF offset in the transverse axis as a diameter offset with the machine data:
MD20360 $MC_TOOL_PARAMETER_DEF_MASK Bit 9 = 1 (definition of tool parameters).
Deselecting an axial DRF compensation (DRFOF) also deletes an existing tool compensation (handwheel
override in tool direction).
Note
For further information about superimposed movements with the handwheel, please refer to:
References:
/FB2/Function Manual, Extended Functions; Jog With/Without Handwheel (H1)
/PG/ Programming Manual Fundamentals (The Programming Guide describes the complete
technical descriptions in order to deselect the DRF offset by axis.)
