D1: Diagnostics tools
5.7 Data lists
Basic Functions
296 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
5.7 Data lists
5.7.1 Machine data
5.7.1.1 Drive-specific machine data
5.7.1.2 NC-specific machine data
Number Identifier: $MD_ Description
1401 MOTOR_MAX_SPEED Speed for max. useful motor speed
1417 SPEED_THRESHOLD_X n
x
for 'n
act
< n
x
' signal
1418 SPEED_THRESHOLD_MIN n
min
for 'n
act
< n
min
' signal
1426 SPEED_DES_EQ_ACT_TOL Tolerance band for 'n
set
-n
act
' signal
1428 TORQUE_THRESHOLD_X Threshold torque
1602 MOTOR_TEMP_WARN_LIMIT Maximum motor temperature
1604 LINK_VOLTAGE_WARN_LIMIT DC link under voltage warning threshold
1620 PROG_SIGNAL_FLAGS Bits variable signal function
1621 PROG_SIGNAL_NR Signal number variable signal function
1622 PROG_SIGNAL_ADDRESS Address variable signal function
1623 PROG_SIGNAL_THRESHOLD Threshold variable signal function
1624 PROG_SIGNAL_HYSTERESIS Hysteresis variable signal function
1625 PROG_SIGNAL_ON_DELAY ON Delay variable signal function
1626 PROG_SIGNAL_OFF_DELAY OFF Delay variable signal function
1700 TERMINAL_STATE Status of binary inputs
1702 MOTOR_TEMPERATURE Motor temperature
1706 DESIRED_SPEED Speed setpoint
1707 ACTUAL_SPEED Speed actual value
1708 ACTUAL_CURRENT Smoothed current actual value
Number Identifier: $MN_ Description
11410 SUPPRESS_ALARM_MASK Mask for suppressing special alarms
11411 ENABLE_ALARM_MASK Activation of special alarms
11412 ALARM_REACTION_CHAN_NOREADY Alarm reaction CHAN_NOREADY permitted
11413 ALARM_PAR_DISPLAY_TEXT Texts as alarm parameters (Siemens Rights)
11420 LEN_PROTOCOL_FILEX File size for protocol files (KB)
13030 DRIVE_MODULE_TYPE Module identifier (SIMODRIVE 611 digital)
