P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1153
14.6 Function interface
14.6.1 Read/write NC variables
14.6.1.1 User interface
The PLC user program can read or write a maximum of eight variables from the NCK area via the PLC/NCK
interface "Read/write NC variable".
The user interface should be operated as follows:
Job specification
Each of the 1-8 variables that should be processed in a job, must be specified via their parameters in the
variable-specific job interface (from offset 1000).
The general identifiers are discussed in more detail later for each variable that can be accessed from the
interface.
Convention: DB120x: The x should be replaced by 0-7 for 1-8 variables.
Action See chapter
1 Specify each individual variable to be read or written, for a write job:
Writing the variables
Job specification [Page
1153]
2 Start job Job management: Start
job [Page 1154]
3 Test and wait until "Job completed" or "Error in job" Job management:
Waiting for end of job
[Page 1155]
4 Evaluate the result interface of each individual variable for validity or
error, for read job: Reading variables
Job evaluation [Page
1156]
5 Reset "start" Job management:
Waiting for end of job
[Page 1155] , Job
management: Cycle
diagram [Page 1155]
DB1200 ...1207 FB2/3 Reading/writing NC data [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB 1000 Variable index
DBB 1001 Area number
DBW 1002 Column index for the NCK variable x (WORD)
DBW 1004 Line index for the NCK variable x (WORD)
DBW 1006
DBD 1008 Write: Data to NCK variable x (data type of the variables: 1…4 bytes)
