K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
677
Program runtime and workpiece counter
9.17.1.3 Axis/spindlespecific machine data
9.17.2 Setting data
9.17.2.1 Channelspecific setting data
28060 MM_IPO_BUFFER_SIZE Number of NC blocks in IPO buffer (DRAM)
28070 MM_NUM_BLOCKS_IN_PREP Number of blocks for block preparation (DRAM)
28080 MM_NUM_USER_FRAMES Number of settable Frames (SRAM)
28090 MM_NUM_CC_BLOCK_ELEMENTS Number of block elements for compile cycles (DRAM)
28100 MM_NUM_CC_BLOCK_USER_MEM Size of block memory for compile cycles (DRAM)
28400 MM_ABSBLOCK Activating basis blocks with absolute values
28402 MM_ABSBLOCK_BUFFER_CONF Dimension size of upload buffer
28500 MM_PREP_TASK_STACK_SIZE Stack size of preparation task (DRAM)
Number Identifier: $MC_ Description
27860 PROCESSTIMER_MODE Activate the runtime measurement
27880 PART_COUNTER Activate the workpiece counter
27882 PART_COUNTER_MCODE[ ] Workpiece counting via M command
Number Identifier: $MA_ Description
30465 AXIS_LANG_SUB_MASK Substitution of NC language commands
30550 AXCONF_ASSIGN_MASTER_CHAN Reset position of channel for axis change
30600 FIX_POINT_POS Fixed value positions of axes with G75
33100 COMPRESS_POS_TOL Maximum deviation with compensation
Number Identifier: $SC_ Description
42000 THREAD_START_ANGLE Start angle for thread
42010 THREAD_RAMP_DISP Acceleration behavior of axis when thread cutting
42100 DRY_RUN_FEED Dry run feedrate
42200 SINGLEBLOCK2_STOPRE Activate debug mode for SBL2
42444 TARGET_BLOCK_INCR_PROG Continuation mode after block search with calculation
42700 EXT_PROG_PATH Program path for external subroutine call EXTCALL
42750 ABSBLOCK_ENABLE Enable basic block display
42990 MAX_BLOCKS_IN_IPOBUFFER Maximum number of blocks in the interpolation buffer
Number Identifier: $MC_ Description
