Siemens SINUMERIK 828D Function Manual

A3: Axis Monitoring, Protection Zones
2.6 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
141
2.6 Data lists
2.6.1 Machine data
2.6.1.1 NC-specific machine data
Axis monitoring
Protection zones
2.6.1.2 Channelspecific machine data
Axis monitoring functions
Number Identifier: $MN_ Description
10604 WALIM_GEOAX_CHANGE_MODE Working area limitation during switchover of geometry
axes
10710 PROG_SD_RESET_SAVE_TAB Setting data to be updated
Number Identifier: $MN_ Description
10618 PROTAREA_GEOAX_CHANGE_MODE Protection zone for switchover of geo axes
18190 MM_NUM_PROTECT_AREA_NCK Number of files for machinerelated protection zones
Number Identifier: $MC_ Description
20150 GCODE_RESET_VALUES Initial setting of the G groups
21020 WORKAREA_WITH_TOOL_RADIUS Allowance for tool radius with working area limitation
24130 TRAFO_INCLUDES_TOOL_1 Tool handling with active transformation 1.
24230 TRAFO_INCLUDES_TOOL_2 Tool handling with active transformation 2.
24330 TRAFO_INCLUDES_TOOL_3 Tool handling with active transformation 3.
24426 TRAFO_INCLUDES_TOOL_4 Tool handling with active transformation 4.
24436 TRAFO_INCLUDES_TOOL_5 Tool handling with active transformation 5.
24446 TRAFO_INCLUDES_TOOL_6 Tool handling with active transformation 6.
24456 TRAFO_INCLUDES_TOOL_7 Tool handling with active transformation 7.
24466 TRAFO_INCLUDES_TOOL_8 Tool handling with active transformation 8.
24476 TRAFO_INCLUDES_TOOL_9 Tool handling with active transformation 9.
24486 TRAFO_INCLUDES_TOOL_10 Tool handling with active transformation 10.
25106 TRAFO_INCLUDES_TOOL_11 Tool handling with active transformation 11.
25116 TRAFO_INCLUDES_TOOL_12 Tool handling with active transformation 12.
25126 TRAFO_INCLUDES_TOOL_13 Tool handling with active transformation 13.
25136 TRAFO_INCLUDES_TOOL_14 Tool handling with active transformation 14.
