S1: Spindles

16.6 Selectable spindles

Basic Functions

Function Manual, 09/2011, 6FC5397-0BP40-2BA0

1329

SETMS(2) ;

SD42800 $SC_SPIND_ASSIGN_TAB[0] = 2 defined internally by NCK.

...

M5 ;

Master spindle = address extension=2, the unset spindle number

is output. M3=5

The physical spindle configured with number "3" stops.

...

GET(S4) ;

Alarm 16105, as logical spindle "4" cannot be switched.

...

RELEASE(S1) ;

Channel spindle "1" = physical. Spindle "5" is enabled.

...

M30
