1008 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
33 :WGEN Commands
PULSe Use these commands to set the pulse signal
parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
• ":WGEN:VOLTage:HIGH" on page 1030
• ":WGEN:VOLTage:LOW" on page 1031
• ":WGEN:FUNCtion:PULSe:WIDTh" on
page 1010
The pulse width can be adjusted from 20 ns to the
period minus 20 ns.
100 mHz to
10 MHz.
20 mVpp to
5Vpp
±2.50 V
DC Use this command to set the DC level:
• ":WGEN:VOLTage:OFFSet" on page 1032
n/a n/a ±2.50 V
NOISe Use these commands to set the noise signal
parameters:
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
• ":WGEN:VOLTage:HIGH" on page 1030
• ":WGEN:VOLTage:LOW" on page 1031
n/a 20 mVpp to
5Vpp
±2.50 V
SINC Use these commands to set the sine cardinal
signal parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
100 mHz to
1MHz
20 mVpp to
5Vpp
±1.25 V
EXPRise Use these commands to set the exponential rise
signal parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
• ":WGEN:VOLTage:HIGH" on page 1030
• ":WGEN:VOLTage:LOW" on page 1031
100 mHz to
5MHz
20 mVpp to
5Vpp
±2.50 V
EXPFall Use these commands to set the exponential fall
signal parameters:
• ":WGEN:FREQuency" on page 1006
• ":WGEN:PERiod" on page 1027
• ":WGEN:VOLTage" on page 1029
• ":WGEN:VOLTage:OFFSet" on page 1032
• ":WGEN:VOLTage:HIGH" on page 1030
• ":WGEN:VOLTage:LOW" on page 1031
100 mHz to
5MHz
20 mVpp to
5Vpp
±2.50 V
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
(High-Z)
1
Offset
(High-Z)
1
