:SBUS<n> Commands 27
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 727
:SBUS<n>:LIN:TRIGger:PATTern:DATA
(see page 1138)
Command Syntax
:SBUS<n>:LIN:TRIGger:PATTern:DATA <string>
<string> ::= "n" where n ::= 32-bit integer in unsigned decimal when
<base> = DECimal
<string> ::= "nn...n" where n ::= {0 |1|X|$}when
<base> = BINary
<string> ::= "0xnn...n" where n ::= {0,..,9 | A,..,F |X|$}when
<base> = HEX
The :SBUS<n>:LIN:TRIGger:PATTern:DATA command specifies the LIN
trigger data pattern searched for in each LIN data field.
Set a <string> bit to "0" or "1" to set the corresponding bit in the data
pattern to low or high, respectively.
Set a <string> bit to "X" to ignore (mask off) that bit in the data pattern.
Use the "$" character to indicate that the value of the corresponding bit
will not be changed (the existing bit value is used).
When <base> = DECimal, the "X" and "$" characters cannot be entered.
When queried, the "$" character is returned when any bits in the pattern
have the value of "X" and <base> = DECimal. When any bits in a given
nibble have the value of "X" and <base> = HEX, the "$" character is
returned for the corresponding nibble.
Query Syntax
:SBUS<n>:LIN:TRIGger:PATTern:DATA?
The :SBUS<n>:LIN:TRIGger:PATTern:DATA? query returns the currently
specified LIN trigger data pattern.
Return Format
<string><NL>
NOTE
<base> is specified with the :SBUS<n>:LIN:TRIGger:PATTern:FORMat command. The
default <base> is BINary.
NOTE
The length of the trigger data value is determined by the
:SBUS<n>:LIN:TRIGger:PATTern:DATA:LENGth command.
NOTE
If more bits are sent for <string> than the specified trigger pattern data length, the most
significant bits will be truncated. If the data length size is changed after the <string> is
programmed, the added or deleted bits will be added to or deleted from the least significant
bits.
