Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

646 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
27 :SBUS<n> Commands
:SBUS<n>:A429:TRIGger:PATTern:DATA
(see page 1138)
Command Syntax
:SBUS<n>:A429:TRIGger:PATTern:DATA <string>
<string> ::= "nn...n" where n ::= {0 |1|X},length depends on FORMat
The :SBUS<n>:A429:TRIGger:PATTern:DATA command defines the ARINC
429 data pattern resource according to the string parameter. This pattern
controls the data pattern searched for in each ARINC 429 word.
Query Syntax
:SBUS<n>:A429:TRIGger:PATTern:DATA?
The :SBUS<n>:A429:TRIGger:PATTern:DATA? query returns the current
settings of the specified ARINC 429 data pattern resource in the binary
string format.
Return Format
<string><NL> in nondecimal format
Errors • "- 241, Hardware missing" on page 1099
See Also • "Introduction to :TRIGger Commands" on page 877
• ":SBUS<n>:A429:TRIGger:TYPE" on page 650
• ":SBUS<n>:A429:TRIGger:PATTern:SDI" on page 647
• ":SBUS<n>:A429:TRIGger:PATTern:SSM" on page 648
NOTE
If more bits are sent for <string> than specified by the :SBUS<n>:A429:FORMat command,
the most significant bits will be truncated.
