Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

:TRIGger Commands 31
Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide 901
:TRIGger[:EDGE] Commands
Table 128 :TRIGger[:EDGE] Commands Summary
Command Query Options and Query Returns
:TRIGger[:EDGE]:COUPl
ing {AC | DC |
LFReject} (see
page 902)
:TRIGger[:EDGE]:COUPl
ing? (see page 902)
{AC | DC | LFReject}
:TRIGger[:EDGE]:LEVel
<level> [,<source>]
(see page 903)
:TRIGger[:EDGE]:LEVel
? [<source>] (see
page 903)
For internal triggers, <level>
::= .75 x full-scale voltage from
center screen in NR3 format.
For external triggers, <level>
::= ±(external range setting) in
NR3 format.
For digital channels (MSO
models), <level> ::= ±8 V.
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal } for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:TRIGger[:EDGE]:REJec
t {OFF | LFReject |
HFReject} (see
page 904)
:TRIGger[:EDGE]:REJec
t? (see page 904)
{OFF | LFReject | HFReject}
:TRIGger[:EDGE]:SLOPe
<polarity> (see
page 905)
:TRIGger[:EDGE]:SLOPe
? (see page 905)
<polarity> ::= {POSitive |
NEGative | EITHer | ALTernate}
:TRIGger[:EDGE]:SOURc
e <source> (see
page 906)
:TRIGger[:EDGE]:SOURc
e? (see page 906)
<source> ::= {CHANnel<n> |
EXTernal | LINE | WGEN} for the
DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | EXTernal | LINE |
WGEN} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
