Agilent Technologies InfiniiVision 3000 X-Series Programmer's Guide

234 Agilent InfiniiVision 3000 X-Series Oscilloscopes Programmer's Guide
7 :ACQuire Commands
:ACQuire:SEGMented:COUNt
(see page 1138)
Command Syntax
:ACQuire:SEGMented:COUNt <count>
<count> ::= an integer from 2 to 1000 (w/4M memory) in NR1 format
The :ACQuire:SEGMented:COUNt command sets the number of memory
segments to acquire.
The segmented memory acquisition mode is enabled with the
:ACQuire:MODE command, and data is acquired using the :DIGitize,
:SINGle, or :RUN commands. The number of memory segments in the
current acquisition is returned by the :WAVeform:SEGMented:COUNt?
query.
The maximum number of segments may be limited by the memory depth
of your oscilloscope. For example, an oscilloscope with 1M memory allows
a maximum of 250 segments.
Query Syntax
:ACQuire:SEGMented:COUNt?
The :ACQuire:SEGMented:COUNt? query returns the current count setting.
Return Format
<count><NL>
<count> ::= an integer from 2 to 1000 (w/4M memory) in NR1 format
See Also • ":ACQuire:MODE" on page 231
• ":DIGitize" on page 199
• ":SINGle" on page 221
• ":RUN" on page 219
• ":WAVeform:SEGMented:COUNt" on page 979
• ":ACQuire:SEGMented:ANALyze" on page 233
• "Introduction to :ACQuire Commands" on page 227
Example Code • "Example Code" on page 235
NOTE
This command is available when the segmented memory option (Option SGM) is enabled.
