5.8 Example 6: Progress bar
The progress bar is a special display type of the input/output field and is designed for display
without input.
Basically there are two progress bar types:
1. Progress bars with up to two color changes, e.g. for temperature or utilization display (see
example 6a)
2. Progress bars to display progress (no color change) in the Operate style (see example 6b)
Example 6a
Progress bar with two color changes:
Figure 5-1 Progress bar with two color changes
DEF PROGGY0 = (R/0,150,50,100///DT1,DO0//"$R[10]"//,,150/3,4,,,,,,,9,7)
Variable type: REAL
Limits / toggle field:
MIN: 0
MAX: 150
Signal value SVAL1: 50
Signal value SVAL2: 100
Attributes:
Display mode DT: 1 (progress bar)
Display option DO: 0 (from left to right (default))
System or user variable: $R[10]
Position of input/output field:
Width: 150
Colors:
Foreground color: 3 (dark green)
Background color: 4 (light gray)
Signal color SC1: 9 (yellow)
Signal color SC2: 7 (red)
To use a progress bar with color change, the display mode DT (DisplayType) must be set to
1.
The orientation of the progress bar is determined via the attribute display option DO
(DisplayOption):
0: From left to right (default)
1: From right to left
2: From bottom to top
3: From top to bottom
Variables
5.8 Example 6: Progress bar
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 89
